The Techspray 2509-GN is a green acrylic conformal coating pen that repairs chips and scratches in green PCB solder resist. Green acrylic conformal coating insulates circuit board traces and components against high voltage arcing. Resist repair pen for PCB rework and repair. It is in the form of clear colorless liquid with sweet ester odor. Ideal for use in electronics manufacturing, repair, and maintenance, the 2509-GN Trace Tech Overcoat Pen provides a quick and targeted method to safeguard sensitive traces, solder joints, and other critical components from environmental factors, such as moisture, dust, and corrosion.

Techspray 2509-GN Trace Tech Overcoat Pen Highlights:

• 110°C Boiling point
• Repairs solder resist
• Non-ozone depleting
• Green to match resist
• Prevents shorting and arcing
• Contain opti/scan for UV inspection
• Repairs scratches & chips in solder resist
• Provides excellent protection from moisture and fungus
• The fast-drying formula ensures minimal downtime, allowing for efficient and swift application, reducing the wait time for the coating to set
• Featuring a conductive formula, this overcoat pen is ideal for enhancing or repairing the conductivity of electronic components, ensuring optimal performance

Techspray 2509-GN Trace Tech Overcoat Pen Specs:

• Brand: Techspray
• SKU: 2509-GN
• Capacity: 5 ml
• Color: Green
• Vapor Density: >1
• Odor: Sweet Ester
• Physical Form: Liquid
• Flash Point: +39.9F
• Product Type: Overcoat Pen
• Applications: Electronic Assembly, Electronic Repair
• Standards Met: OSHA, IPC Standard 7711, ANSI J Standard 001C
• Chemical Component: n-Propyl Acetate, Acetone, Acrylic Polymer
