The C245-785 is a C245 Series Solder Tip Cartridge. This tip features a Barrel shape, ideal for drag soldering through-hole component leads. The C245-785 tip cartridge offers an overall tip width of 0.157" (4mm) x 0.295" (7.5mm) overall Length. The tips barrel diameter measures 0.118" Outer Diameter (3mm) x 0.059" Inner Diameter (1.5mm) x 0.024" (0.6mm) Deep. The C245 Series cartridges are designed for use with the T245-A, T245-PA and T245-NA Soldering Irons.

JBC C245785 Cartridge Pin Connector Soldering Tip Highlights:

• C245 cartridge range is JBC's widest one, with many shapes, sizes and special models
• Appropriate for general soldering purposes and they are perfect for both SMD components or for applications with high power requirements such as ground plane soldering
• Works with T245 Handpieces
• JBC Long Life Tips offer instant heat up, excellent heat transfer and great durability

JBC C245785 Cartridge Pin Connector Soldering Tip Specs:

• Brand: JBC Tools
• SKU: C245785
• Product Type: Soldering Tip
• Style: Barrel
• Tip Width (Overall): 0.157" (3mm)
• Tip Length (Overall): 0.295" (7.5mm)
• Barrel Outer Diameter (OD): 0.118" (3mm)
• Barrel Inner Diameter (ID): 0.059" (1.5mm)
• Barrel Depth: 0.024" (0.6mm)
