The Desco 74203 ESD-Safe Statshield Pink Jacket with Knitted Cuffs offers a minimum of 9% carbon conductive nylon fibers woven In chain-link design. This provides continuous and consistent charge dissipation throughout lifetime of smock.Statshield smocks are designed to be anti static, low tribo charging, and create a faraday cage around the torso and arms of the wearer to protect ESD susceptible items from ESD electrostatic fields generated by clothing on the operator's clothing. Statshield smocks incorporate a hip-to-cuff grounding feature which allows for hands-free grounding with no cord attached to the operator's wrist. This feature allows connection of a ground cord to a 4mm snap stud on the hip. A seam of carbon-suffused threads provides a secure and direct electrical connection from the snap stud on the hip to conductive elastic cuffs. Standard touch testing or continuous monitoring can be used to test the function.

Desco 74203 Statshield ESD-Safe Jacket Highlights:

• Groundable Static Control Garment System Tested Per ANSI/ESD S20.20-2014 (Rtg < 3.5 X 107 ohms) Requirements, per ANSI/ESD STM2.1
• Allows operators and smock to be bonded or electrically connected to ground to prevent ESD events in ESD Protected Areas.
• Minimum of 9% Carbon Conductive Nylon Fibers Woven In Chain-Link Design
• Provides continuous and consistent charge dissipation throughout lifetime of smock.
• Creates Faraday Cage Effect Around Torso And Arms Of Operator
• Shields ESD charges from operators’ clothing from damaging ESD sensitive devices.
• Panel To Panel Conductivity
• Prevents isolated charged conductor in ESD Protected Area.
• Hip-To-Cuff Grounding
• Grounds operator with no need for a cord to be attached to the operator's wrist.
• Badge Holder Tab
• Secure badge holders to tab to avoid damage to other parts of the smock.
• Two Sleeve Pen Pockets
• Holds pens or small tools in safe and convenient location for operator.
• 2-Year/100 Launderings Limited Warranty
• Extended lifetime of garment will maintain its electrical and ESD properties.

Desco 74203 Statshield ESD-Safe Jacket Specs:

•  Brand: Desco
•  SKU: 74203
• Collar: Lapel Collar
• Color: Pink
• Conductive Knitted Cuffs: Yes
• Cuff Style: Knitted Cuffs
• ESD-Safe: Yes
• Fabric: Texturized polyester and a minimum of 9% carbon mono-filament nylon.
• Hip To Cuff Grounding: Yes
• Pockets: Yes
• Size: Large
• Style: Jacket
• Surface Resistivity: 14 x 105 < 1 x 107 ohms per ANSI/ESD STM2.1 and ESD TR53 of Fabrics
