The Chemtronics CM8 Chemask is a fast curing peelable solder masking agent. It contains natural latex formulated with high temperature resistant compounds that protect component-free areas during wave soldering. Chemask® may be used to protect pins, posts, contacts and edge connections during conformal coating processes.

Chemtronics CM8 Chemask Fast Curing Peelable Temporary Solder Masking Agent Highlights:

• Stable to 515 degree F/268 degree C
• Compatible with rosin, water soluble fluxes and cleaning solvents
• Leaves no residue
• Dries tack free in 30 minutes
• Non-contaminating
• Dries tack-free in 30 minutes
• Easy to use just peel off dried Chemask masking agent
• Latex material is compatible with flux systems and stable with cleaning solvents
• Natural latex has superior strength and elongation:can stretch to five times cured length without breaking
• Ideal for protecting contacts during wave soldering
• Use as a protective mask during conformal coating process for switches, pins, posts, contact and edge connections
• Chemical Component: Natural Latex Rubber; Methanol; Titanium Dioxide
• Applications: Component Free Areas, Components, Pin Connectors, Temperature Sensitive Components

Chemtronics CM8 Chemask Fast Curing Peelable Temporary Solder Masking Agent Specs:

• Brand: Chemtronics
• SKU: CM8
• Product Type: Solder Masking Agent
• Physical Form: Liquid
• Color: Pale Pink
• Flash Point: Nonflammable
• Cure Time: 30 min @ 77°F
• Viscosity: 20000 to 28000 @ 77°FcPs
• Container Type: Squeeze Bottle
• Length: 6.0 in
• Width: 2.0 in
• Height: 2.0 in
• Capacity: 8oz
• Storage Conditions: COOL DRY PLACE
• Standards Met: MIL-STD-2000A, ACGIH, NIOSH, OSHA
• View our Chemtronics SDS Sheets Here
