The ASG TPU 1 is an ESD-Safe eTensil Series Power Supply. This basic power supply works in complete synchronization with the eTensil Series Electric Torque Screwdrivers. The TPU 1 provides electrical power levels appropriate for each operational mode, while consistently monitoring key working procedures. The power supply activates the various available functions, increases the program-ability and controls the other customization features for which the screwdriver is designed. Along with monitoring key working procedures, the TPU 1 offers integrated LED indication lights. The TPU 1 Power Supply features two (2) rotational speeds (RPM Speeds), controlled via a membrane switch allowing the user to set the driver to which speed works best for the application.

ASG TPU-1 Fiam Etensil Basic Power Supply Highlights:

• Allows the user to monitor key working procedures
• LED signaling
• Two rotation speeds A membrane switch allows the user to set two rotation speeds. LOW is a reduction of the driver’s maximum speed by approximately 20%
• Fixing Plate accessory available upon request to position unit on any surface

ASG TPU-1 Fiam Etensil Basic Power Supply Specs:

• Brand: ASG
• SKU: TPU-1
• Series: Etensil
• Type: Single Tool
• Input Voltage: 230v AC (± 10%)
• Output Voltage (Approx.): 32v DC
• No. Drivers (Max.): One (1)
• Dimensions: 7.2" x 5.9" x 2.5" (185 x 150 x 63mm)
